Description
|
Overall length |
42 in |
RAM |
YES |
|
Overall width |
80 in |
gearbox HP |
50 |
|
Overall height |
37 in |
||
|
Working width |
71 in |
Number of Hammers |
24 |
|
42 / 29 in |
Transmission: PTO |
540 |
|
|
24 / 47 in |
3 point linkage |
I II |
|
|
Transmission: RPM Rotor speed |
2,146 |
Belts quantity |
4 |
|
A (Rotor: diameter) |
φ7 x 0.3 in |
Belt Tension Adjustable |
Manual |
|
B (Rotation diameter of the cutting edge) |
16 |
Weight （INCLUDED PTO SHAFT） |
1,382 lbs |
|
C (Distance from the center of the rotor to the top of the inner side of the hood) |
9 in |
Tractor Power Range |
30-85 HP |
|
D(Rear roller: diameter) |
φ6 x 0.2 in |
Gearbox Oil Type |
SAE90 EP Gear Oil |
|
Packing sizes |
83 x 48 x 41 in |
||
|
Tip speed (approx.) |
**151 ft/s** |
Packaging weight |
1,544 lbs |
|
Openable maintenance door |
YES |
