Description
Product Highlights
- Improve productivity with easy access on and off the machine with up to 10.5 gallons of fuel capacity to mow longer with fewer stops.
- Exceptional visibility from the GrandStand protects the operator, the mower and the property. The operator is better able to steer clear of obstacles, and easily pass beneath branches.
- Toro’s foldable operator platform instantly converts the GrandStand to a walk-behind. It easily lowers back down when its time to ride – saving time, money and trailer space by eliminating the need to switch mowers.
- Conserves space to get more machines on your trailer, or allows for a smaller trailer and lighter load.
Specifications
- Engine
22 hp (16.4 kw) Kawasaki FX 726cc - Fuel Capacity
Gas/10.5 gal (39.7 L) - Cutting Width
48″ (122 cm) - Adjustable Discharge Baffle
Standard - Air Filter
Heavy-Duty Canister Air Cleaner - Blade Tip Speed
18,500+ ft/min - Blade Type
.25″ (.6 cm) heat-treated steel - Carrier Frame
3″ x 1.5″ (7.6 cm x 3.8 cm) x 12 gauge - Caster Tires
11″ x 5″-5″ (28 x 13-13 cm) flat free semi-pneumatic - Clutch
Electromagnetic - Deck Design
80-grade 7-gauge 48″ (122 cm) TURBO FORCE® w/bull-nose bumper - Discharge Chute
Rubber - Drive System
Pumps (10cc/rev) & Wheel Motors (10 cir) - Drive Tires
20″ x 10.5″- 8″ (51 x 26.67 – 20 cm) - Engine Displacement
726cc - Ground Speed
Up to 10 mph forward (16.1 km/h) - Height of Cut
1″ – 5″ in 1/4″ (2.5 cm – 12.7 cm in 6 mm) increments - Hour Meter
Standard - Hydraulic Fluid
Premium synthetic - Spindle Bearings
Greaseless ball bearings - Spindle Housing
9″ (22.9 cm) diameter cast aluminum - Steering Controls
Twin lever - Weight
890 lbs. (403.7 kg)
