Description
Key specs for fitment, grinding depth, and operating setup.
| Specification | Details |
| Tractor HP | 25–60 HP |
| Hydraulic Control Valve | Included |
| Hitch Compatibility | CAT.1 / CAT.2 (Quick Hitch Compatible) |
| Maximum Cutting Height Above Ground | 24 in |
| Maximum Grinding Depth Below Grade | 12 in |
| Recommended Cutting Depth Per Pass | 6 in |
| Flywheel Diameter | 24 in |
| Number of Teeth | 56 pcs |
| Tooth Material | YG10C carbide |
| Swing Arc | 65° |
| PTO Speed | 540 RPM |
| PTO Shaft | 1-3/8″ 6-spline PTO driveline with slip clutch |
| Flywheel Speed | 810 RPM |
| Flywheel Thickness | 0.79 in |
| Gearbox HP | 60 HP |
| Net Weight | 820 lbs (PTO shaft included) |
| Protective Guard | Rubber |
📌 Depth Note: The HSG24PRO can grind up to 12 in below grade, with a recommended cutting depth of up to 6 in per pass for controlled, efficient operation.
