Description
The 2000 Series has overhead valve design for better fuel efficiency, and user-friendly features like Accu-Fill and Easy-Pull technology.
Features
- Designed for effortless starts with electronic ignition
- Easy-pull ergonomic handle
- Easy pours and less spilling with Accu-Fill® fuel tank’s 45% larger angled fuel neck
- Simple starts and stops with all-in-one throttle/choke/shut-off control lever
- Lightweight design makes for easy maneuverability
This engine powers the following equipment:
- Chipper
- Edger
- Tiller
- Go-Kart
- Log Splitter
- Pressure Washer
- Pump
Specifications:
| Crankshaft Diameter | 1″ |
| Displacement cm3 (in3) | 196 (12) |
| Bore mm (in) | 68 (2.7) |
| Stroke in mm (in) | 54 (2.1) |
| Maximum Torque Nm (lb-ft) | 14.5 (10.7) @ 3000 rpm |
| Dry Weight kg (lbs) | 16 (28.8) |
| Oil Capacity L (US qt) | 0.6 (0.63) |
| Engine Type | Consumer |
| Compression Ratio | 8:5:1 |
| Lubrication | Splash |
| Dimensions L x W x H mm (in) | 310x329x325 (12.2×12.8×12.8) |
Horsepower ratings meet Society of Automotive Engineers Small Engine Test Code J1940. Actual engine horsepower maybe lower and affected by, but not limited to, accessories (air cleaner, exhaust, charging, cooling, fuel pump, etc.), application, engine speed and ambient operating conditions (temperature, humidity and altitude). For more information, contact Rehlko Engine Engineering department.
If you have any questions, give us a call during business hours and one of our friendly associates will be happy to assist you. 410-692-5170
